Model AS14
Heavy Duty
Condensing Unit Stand
Model AS14
Heavy Duty Condensing Unit Stand
Heavy Duty Condensing Unit Stand
- Category:Condensing Unit Stands
- Material:6061-T6 Aluminum
- Miami-Dade NOA#: 20-1013.03
- Florida State Approval #:FL24546-R3
- U.S. Patent Protected:9,052,120
- FBC AS14 Calculator: FBC Calculator
- FBC 8th Edition (2023) Engineering Data: Download Engineering
- AS14 Specification Sheet: Download Spec. Sheet
- Cross-Mounting Bar Engineering: Download Engineering
- Vibration Pad Specification Sheet: Download Spec. Sheet
- Purchase: Find Distributors
Product Description
Florida Building Code 8th Edition (2023) compliant.
Aluminum 6061-T6 alloy construction.
Engineered to accommodate the larger SEER 13 units.
Available with optional cross-mounting angle.
Available with optional, customer provided rubber boots.
Available with optional electrical box mounting bracket (EMB).
Available with optional vibration pad to isolate vibration from condensing unit.
Engineer’s raised-seal drawings available.
Standard Assembly
| Part No. | Description |
|---|---|
| AS14S18 | Standard Leg Assembly, 20"-30" spread, 18" tall |
| AS14S24 | Standard Leg Assembly, 20"-30" spread, 24" tall |
| AS14S30 | Standard Leg Assembly, 20"-30" spread, 30" tall |
Heavy Duty Assembly
| Part No. | Description |
|---|---|
| AS14H18 | Heavy Duty Leg Assembly, 34"-42" spread, 18" tall |
| AS14H24 | Heavy Duty Leg Assembly, 34"-42" spread, 24" tall |
| AS14H30 | Heavy Duty Leg Assembly, 34"-42" spread, 30" tall |
I-Beams
| Part No. | Description |
|---|---|
| ASI-3 | Aluminum Stand I-Beam, 3' |
| ASI-6 | Aluminum Stand I-Beam, 6' |
| ASI-9 | Aluminum Stand I-Beam, 9' |
| ASI-12 | Aluminum Stand I-Beam, 12' |
| ASI-15 | Aluminum Stand I-Beam, 15' |
| ASI-18 | Aluminum Stand I-Beam, 18' |
Cross Mounting Angle
| Part No. | Description |
|---|---|
| ASCAB-30 | 3" x 3" x 1/8" In-Beam Cross Mount Angle for 30" spread |
| ASCAB-36 | 3" x 3" x 1/8" In-Beam Cross Mount Angle for 36" spread |
| ASCAB-42 | 3" x 3" x 1/8" In-Beam Cross Mount Angle for 42" spread |
AS14 Options
Cross Mounting Angle
Electrical Mounting Bracket
